HIKVISION : DS-E16HGHI-B
*Specifications as per manufacturer, subject to change without notice.
Non-returnable
₹10,400.00
Available Offer
Share :
Product Details
HIKVISION DS-E16HGHI-B 16-Channel 1080p Lite eSSD DVR | H.265 | Motion Detection 2.0
- Deep-learning Motion Detection 2.0 for human and vehicle classification
- Reduces false alarms caused by leaves, lighting and other non-target movement
- Supports up to 2 IP cameras up to 5MP
- Up to 16-channel synchronous playback
- Up to 1080p Lite recording at 15 fps by default
- Built-in eSSD eliminates the need for a separate HDD
- Hik-Connect remote monitoring support
- Compact 1U form factor
Technical Specifications
| Specification | Details |
|---|---|
| Brand | HIKVISION |
| Model | DS-E16HGHI-B |
| Product Type | 16-Channel eSSD DVR |
| Analog Video Input | 16 × BNC |
| IP Video Input | 2 Channels, up to 5MP |
| Video Formats | HDTVI / HDCVI / AHD / CVBS / IP |
| Recording Resolution | 1080p Lite / 720p / 720p Lite / WD1 / 4CIF / CIF / QVGA |
| Video Compression | H.265 Pro / H.265 |
| AI | Motion Detection 2.0 – Human & Vehicle |
| Storage | Built-in 1024GB eSSD |
| Available Storage | 960GB |
| Approx. Recording Capacity | About 2 weeks for 16 analog cameras under default parameters* |
| Audio Input | 16-Channel Coaxial Audio |
| Audio Output | 1-Channel via HDMI |
| Synchronous Playback | 16 Channels |
| HDMI Output | 1920 × 1080 @ 60Hz |
| VGA Output | 1920 × 1080 @ 60Hz |
| Network | 10/100 Mbps RJ45 |
| Total Bandwidth | 96 Mbps |
| Incoming Bandwidth | 8 Mbps |
| Remote Connection | Up to 128 |
| USB | 2 × USB 2.0 |
| Power Supply | 12V DC, 1A |
| Power Consumption | ≤9.5W with eSSD |
| Dimensions | 235 × 146.6 × 46.6 mm |
| Weight | ≤0.5kg |
*Storage note: The device can store approximately 2 weeks of video from 16 analog cameras using default parameters. Actual recording duration varies with camera resolution, frame rate, bitrate, motion activity and recording settings. This estimate is for reference only.
Product Description
The HIKVISION DS-E16HGHI-B is a compact 16-channel eSSD CCTV DVR with built-in 1TB eSSD storage, Motion Detection 2.0 and human/vehicle classification. It supports HDTVI, HDCVI, AHD, CVBS and IP cameras, along with H.265 Pro compression and scene-adaptive bitrate control for efficient recording.
Ideal For
- Homes & Villas
- Retail Stores
- Offices
- Warehouses
- Schools & Institutions
- Commercial CCTV Projects
