CP PLUS : DNW-GPU8G2F2-N12
Non-returnable
₹3,066.00
Available Offer
Share :
Product Details
CP PLUS 12 Port Gigabit PoE Switch | 8 PoE + 2 Gigabit RJ45 + 2 SFP Uplink | 120W | DNW-GPU8G2F2-N12
Key Features
- 8 × 10/100/1000Mbps Gigabit PoE Ports
- 2 × Gigabit RJ45 Uplink Ports
- 2 × Gigabit SFP Uplink Ports
- IEEE 802.3af/at/bt PoE Support
- 120W Total PoE Power Budget
- Up to 60W PoE Output Per BT Port
- AI PoE Watchdog for Automatic Camera Recovery
- Auto MDI/MDIX Support
- Store-and-Forward Switching
- Intelligent Power Distribution
- 6KV Lightning Protection
- Zero Configuration Plug & Play Design
Technical Specifications
| Specification | Details |
|---|---|
| Brand | CP PLUS |
| Model | DNW-GPU8G2F2-N12 |
| Total Ports | 12 Ports |
| PoE Ports | 8 × Gigabit RJ45 |
| RJ45 Uplink Ports | 2 × Gigabit |
| SFP Uplink Ports | 2 × Gigabit |
| PoE Standard | IEEE 802.3af / at / bt |
| PoE Power Budget | 120W |
| Max. PoE Output | Up to 60W (BT Port) |
| Switching Bandwidth | 24Gbps |
| MAC Address Table | 8K |
| Transmission Distance | Up to 100m |
| Watchdog | AI PoE Watchdog (Ports 1–8) |
| Lightning Protection | 6KV |
| Power Input | AC 180–240V |
| Operating Temperature | -30°C to +60°C |
| Dimensions | 187 × 139 × 43 mm |
| Warranty | 2 Years |
Product Description
The CP PLUS DNW-GPU8G2F2-N12 is a 12-port unmanaged Gigabit PoE switch designed for professional IP surveillance and enterprise networking. It features 8 Gigabit PoE ports, 2 Gigabit RJ45 uplinks, and 2 Gigabit SFP uplink ports for high-speed data transmission and flexible fiber connectivity.
With a 120W PoE power budget, up to 60W BT PoE output, AI PoE Watchdog, and 24Gbps switching bandwidth, this switch ensures reliable power delivery and uninterrupted operation for IP cameras, wireless access points, VoIP phones, and other PoE devices. Its plug-and-play design makes deployment quick and hassle-free.
Applications
- IP CCTV Surveillance Systems
- Enterprise Networks
- Offices & Commercial Buildings
- Wireless Access Points
- VoIP Phone Networks
- Hotels & Hospitals
- Educational Institutions
- Industrial Network Infrastructure
Package Contents
- 1 × CP PLUS DNW-GPU8G2F2-N12 PoE Switch
- AC Power Cable
- Installation Manual
